Dapol 4S-028-003S

SECR Maunsell D1 Class Southern SR Maunsell Olive Green 4-4-0 Steam Locomotive (with Top Feed) No.1741 (DCC Sound)

Manufacturer catalogue image - please note that pre-release images may be CAD renders or CGI images rather than photographs

Prototype Era
Era 3 (1923 to 1947) The Big Four (LNER, LMS, GWR and SR)

Manufacturer description

Exclusive Model, Produced by Dapol.

Brief History:

After 1901 the D class locomotive fast became the mainline locomotive of choice on the south coast, (making the SE&CR’s first mainline express formation) further (for the time) powerful locomotives were investigated by the companies. After Richard Maunsell took the reigns from Harry Wainwright in 1913 he worked on a series of new locomotives which were intended for a long service life, this involved the conversion and upgrade of 11 E class locomotives, resulting in the E1 class. This proved very successful and led directly to the conversion of 21 D class into the D1 class between 1921 and 1927. Though arguably, not as elegant as the D class equipped with a larger boiler, a belpaire firebox and longer travel cylinders the D1 was able to produce a considerable haulage and power increase over its predecessors.

Initially allocated to Ashford shed, this class was to be found all over the south-eastern division from London to the south.

Withdrawn in November 1961, no preserved examples exist.

Specification:

Technical Specification
• Diecast Chassis
• Low centre of gravity located between the driving wheels
• NEM couplings with removable coupling pocket
• Sprung buffers
• R2 (438mm/17.2”) minimum radius
• Pickup from tender and driving wheels
• Powerful 5 pole motor located within boiler
• Pull Out PCB for a tool-free DCC & Speaker fitting.
• ‘Snap-fit’ conductive tender drawbar
• Options for bass reflex speaker in tender (pre-wired)
• Firebox glow
• Profiled wheels
• Detailed motion
• Removable coal load with internal tender profiling
• Fully detailed back-head and cab interior.
• Back by Dapol’s comprehensive warranty and service

Variations (dependent on model represented)

• Two frame variations (to include early D class conversions)
• Two cab types
• Two Chimney types
• Two Smokebox types
• Three dome types (with/without top feed and plated)
• Two safety valve types (Ross-pop and Ramsbottom)
• With and without snifter valves
• ‘High capacity’ tenders
• Manual and automatic lubricators
• Additional minor detail variations





Catalogue listing

Model details

Prototype information

The Dapol SECR Maunsell D1 Class Southern SR Maunsell Olive Green 4-4-0 Steam Locomotive is a limited edition model produced by Dapol, in collaboration with Rails of Sheffield.

This model represents a locomotive from the Big Four period, which spanned the late 1920s to the early 1940s, during which time the Southern Railway was one of the major railway companies in the UK.

The D1 Class locomotive was a development of the E class, with 11 E class locomotives being converted and upgraded between 1921 and 1927. The D1 Class was designed to provide a significant increase in power and haulage capacity, and was initially allocated to Ashford shed, with examples operating throughout the south-eastern division.

The model features a diecast chassis, low centre of gravity, NEM couplings, sprung buffers, and a 5 pole motor located within the boiler. Additional features include a pull-out PCB for easy DCC and speaker fitting, a conductive tender drawbar, and a range of detailing options.

This model is a limited edition, and as such, it is not expected to be re-released. It is available with DCC sound, and features a comprehensive range of detailing options, including two frame variations, two cab types, and a range of chimney, smokebox, and dome types. The model is also available with or without a bass reflex speaker in the tender, as well as manual and automatic lubricators, and additional minor detail variations.

The D1 Class locomotive was withdrawn from service in November 1961, and no preserved examples exist today.
